Prolynx – Access Control & Attendance Machine Swing Gate – PL-SG004+DSG001
CFA 0
Key Features
- 8-inch touch vertical screen with binocular camera
- Ultra-thin aluminum alloy casing, beautiful and stylish.
- Support identification under harsh conditions such as darkness, low light, and strong light.
- Large capacity, support for local comparison.
- Wisdom community, office building, government agencies, finance, mining, education exams, hotels, ports, stations,base access control, subway security and other full-scale scenes.
- Size: 1400x185x1020mm
- Unlock time: 0.2s
- Pass rate: 35 person/min
- Pass width: ≤900mm
- Input: 100V~240V
- Motor voltage: 24v
- Environment: -25~+70
- Power consumption: 35w
| Product Size: | 1400*185*1020mm |
|---|---|
| Pass Width: | 600-900mm |
| Net Weight: | 195kg |
| Thickness: | 1.2mm |
| Material: | 1.2mm SUS 304 Hailine 400# |
| Top cover Material: | Acrylic+1.5mm SUS304 |
| Filling Panel Material: | 10mm Transparent Acrylic |
| Arm Material: | 10mm Transparent Acrylic |
| Driver: | Brushed Motor |
| Infrared Sensor: | 5pairs |
| Pass Rate: | 35-40p/m |
| Power Supply: | 100-240V(AC) |
| Operational Voltage | 24V(DC) |
| Max Power Consumption | 35w |
| Frequency: | 50-60hz |
| Working Temperature | -25 to +70°C |
| MCBF | 5,000,000cycles |
| Access Control | CARD/QR/FACE/FINGER (1 set optional) |
| Face Recognition Module | : |
| Usage | Wall-mounted, Turnstile-mounted |
| Screen | 8. TFT screen 800(H)X3(RGB)X1280(V) |
| ROM | 16GB EMMC |
| RAM | 2GB DDR3 |
| CPU | Quad-core Cortex-A17, 1.8Ghz |
| OS | Android |
| Storage | 10,000 users |
| Working Range | gister: 60cm-100cm, Recognize: 60cm-150cm |
| Communication | TCP/IP |
| Dimension | 235mm(L)*130mm(W)*25mm (H) |
| Operation Tips | LCD tips, language wizard and lighting tips |
| Camera | 1*1.3MP infrared sensor face + 1*3MP Visible face (wide dynamic) |
| Voltage | DC 12V, 4A |
| Function | Button – opening button |
| Interface | RJ45, RS232, Wiegand 26/34 output, Relay, AUX, USB port |
| Application Environment | Temperature: -20-50°C Humidity: 25-85% |
| Recognition Method | Infrared sensor face, Visible face |
